SafeCopy manually finish ISO

2 votes
1 answer
2012 views
Good Morning, I am currently helping a good friend to recover her broken 1TB external HDD. She dropped the drive and now, it cannot be mounted anymore. After some research I gave safecopy a try. I am working with a Kali Linux live CD and an internal 3TB HDD that is connected and mounted via USB station. The external drive has less than 100GB space occupied. SafeCopy collects ~30GB per day. My first try aborted after ~260GB with an "location not found" error, the drive has reconnected to another mount path. The current try is at ~280GB. Since the drive is brand new, all stored data should already be collected in the output ISO. However, when I try to mount the 260GB ISO I get an file error, something about corrupted file and I/O error I used this command for safecopy: sudo safecopy --stage1 /dev/sda1 /path/to/3tb/drive/data.iso /dev/sda1 is the place where the external HDD is detected. Is there a way to manually finish the build of the ISO file? This would save me a lot of time, since safecopy would need ~34 days to complete the job. EDIT: As mentioned in the comments, I had to abort the process for some time. I've now set it all up again and after some difficulties, this is what fdisk produced: sudo fdisk -l /dev/sdc1 Disk /dev/sdc1: 931.5 GiB, 1000169537536 bytes, 1953456128 sectors Units: sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disklabel type: dos Disk identifier: 0x69205244 Device Boot Start End Sectors Size Id Type /dev/sdc1p1 ? 218129509 1920119918 1701990410 811.6G 72 unknown /dev/sdc1p2 ? 729050177 1273024900 543974724 259.4G 74 unknown /dev/sdc1p3 ? 168653938 168653938 0 0B 65 Novell Netware 386 /dev/sdc1p4 2692939776 2692991410 51635 25.2M 0 Empty Partition table entries are not in disk order. I forgot to save the stage1.badblocks file, so I cannot really continue the first run. I now started a new stage1 safecopy run, hope it will be a bit faster than before since I now run a Debian Linux directly from this notebook. Since then, is there a way to use the iso files from the first run and make it readable? EDIT2: Ok, after 3 hours, this is the output so far: (+0){XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXX 8-X 0% the drive makes terrible clicking noises. If I interprete the fdisk output form earlier, the data seems to be written way more back on the drive, not from sector 0 onwards. Is it possible to read and rescue the data by starting at the end of the disk? I fear I am more or less dependant on extracting the data from the iso file I created so far. Again, i it somehow possible to extracxt portions from an unfinished iso file and build a valid one from it? EDIT 3: I now tried ddrescue. It now runs for ~ 23h. The output file has a size of 134MB, the size I already knew from safecopy to be ok. gmesg | tail produces the following output: [80840.705000] usb 2-1.1: reset high-speed USB device number 8 using ehci-pci [80880.711821] usb 2-1.1: reset high-speed USB device number 8 using ehci-pci [80920.718561] usb 2-1.1: reset high-speed USB device number 8 using ehci-pci [80922.888408] sd 8:0:0:0: [sdb] Unhandled error code [80922.888413] sd 8:0:0:0: [sdb] [80922.888415] Result: hostbyte=DID_TIME_OUT driverbyte=DRIVER_OK [80922.888417] sd 8:0:0:0: [sdb] CDB: [80922.888419] Read(10): 28 00 49 a5 38 80 00 00 08 00 [80922.888426] end_request: I/O error, dev sdb, sector 1235564672 [80922.888430] Buffer I/O error on device sdb1, logical block 154445328 So what I can see there is that there are difficulties with the usb access and something with hostbyte=DID_TIME_OUT dd has this output so far: rescued: 123928 kB, errsize: 0 B, current rate: 12976 kB/s rescued: 134742 kB, errsize: 39649 kB, current rate: 0 B/s ipos: 635829 MB, errors: 605, average rate: 1688 B/s ago opos: 635829 MB, run time: 22.17 h, successful read: 22.01 h ago Copying non-tried blocks... Pass 1 (forwards) After dd has finished I will try to extract at least a little bit with tsk_recover from the dd image. As mentioned in the comments I looked up the hardware specs of the drive. THe problem is that the USB connector (USB 3.0 Type B Micro) is placed on the main PCB so I cannot access a ATA/SATA connection. Or at least thats what I found out (I didn't open the case so far). I couldn't find a data sheet with circuit diagram. The product number is WDBHHG0010BBK-04. I found a video of a similar looking (!) drive that has pins next to the usb port. I don't know enough about hard drives and electronics to see if I could use these. As soon as dd finished I will open the case. I am asking myself what could have damaged the drive that bad. My friend told me she just dropped it. It seems like the rw head is damaged or has smashed the disk. As far as I know, HDDs move their heads aside while idle or powered off. My attempts of rescue seem to have not dealt much more damage since the result of readable sectors are the same as from the start. So, much text. my current question is what the syslog entries should tell me. Some Pics of the drive: enter image description here enter image description here enter image description here
Asked by Ueda Ichitaka (81 rep)
Aug 18, 2016, 09:20 AM
Last activity: Jun 25, 2025, 04:03 AM
