Roadwarrior scenario strongswan- Iphone setup

I'm working on trying to set up a roadwarrior client scenarion VPN with Stringswan on a raspberry pi. The server config looks like this: pi@raspberrypi:~ $ sudo cat /etc/ipsec.conf # ipsec.conf - strongSwan IPsec configuration file config setup uniqueids=never charondebug="cfg 2, dmn 2, ike 2, net 2" conn %default auto=add keyexchange=ikev2 ike=aes128-sha256-ecp256 esp=aes128-sha256-ecp256 dpdaction=clear dpddelay=300s dpdtimeout = 5s forceencaps=yes fragmentation=yes keyingtries=5 rekey=yes left=%any leftfirewall=yes leftid=MYDNSNAME leftsubnet=0.0.0.0/0 leftcert=vpnGatewayCert.pem leftsendcert=always mobike=yes right=%any rightdns=1.1.1.1,1.0.0.1 rightsourceip=192.168.122.101/24 ## LOCAL IP RANGE FOR VPN CONNECTED DEVICES type=tunnel conn IKEv2 rightauth=pubkey include /var/lib/strongswan/ipsec.conf.inc I also modified the secrets like this: nano /etc/ipsec.secrets # This file holds shared secrets or RSA private keys for authentication. # RSA private key for this host, authenticating it to any other host # which knows the public part. # this file is managed with debconf and will contain the automatically created $ include /var/lib/strongswan/ipsec.secrets.inc : ECDSA vpnGatewayKey.pem I also created a CA on the raspberry pi, created the strongswan certificates and created a client certificate bundle .p12 file with the following commands: cd /etc/ipsec.d/ #creating CA Key ipsec pki --gen --type ecdsa --size 521 --outform pem > private/CA_strongswanKey.pem chmod 600 private/CA_strongswanKey.pem #creating CA certificate ipsec pki --self --ca --lifetime 3650 --in private/CA_strongswanKey.pem --type ecdsa --dn "C=CH, O=strongSwan, CN=strongSwan Root CA" --outform pem > cacerts/CA_strongswanCert.pem #creating server key ipsec pki --gen --type ecdsa --size 521 --outform pem > private/vpnGatewayKey.pem chmod 600 private/vpnGatewayKey.pem #creating serverCert ipsec pki --pub --in private/vpnGatewayKey.pem --type ecdsa | \ ipsec pki --issue --lifetime 730 \ --cacert cacerts/CA_strongswanCert.pem \ --cakey private/CA_strongswanKey.pem \ --dn "C=CH, O=strongSwan, CN=MYDNSNAME" \ --san MYDNSNAME \ --flag serverAuth --flag ikeIntermediate \ --outform pem > certs/vpnGatewayCert.pem #Client Key ipsec pki --gen --type ecdsa --size 521 --outform pem > private/ClientKey.pem chmod 600 private/ClientKey.pem #Client cert ipsec pki --pub --in private/ClientKey.pem --type ecdsa | \ ipsec pki --issue --lifetime 730 \ --cacert cacerts/CA_strongswanCert.pem \ --cakey private/CA_strongswanKey.pem \ --dn "C=CH, O=strongSwan, CN=Client Key" \ --san Client_Key \ --outform pem > certs/ClientCert.pem #Exporting client bundle openssl pkcs12 -export -inkey private/ClientKey.pem \ -in certs/ClientCert.pem -name "Client's VPN Certificate" \ -certfile cacerts/CA_strongswanCert.pem \ -caname "strongSwan Root CA" \ -out Client.p12 Now I checked and made sure port 500 and 4500 are properly forwarded to the raspberry pi. I downloaded over the .p12 file made in the previous step to my iphone and imported it as a profile. I also imported the vpnGatewayCert.pem and the CA_strongswanCert.pem into my iPhone so it would trust the ipsec gateway server! When I try to connect the IPhone to the vpn I get an error on the iphone. In the logs of strongswan I see this: Sep 29 16:18:45 raspberrypi charon: 13[IKE] received end entity cert "C=CH, O=strongSwan, CN=Client Key" Sep 29 16:18:45 raspberrypi charon: 13[CFG] looking for peer configs matching 192.168.123.101[myDNSNAME]...94.109.49.167[10.218.49.167] Sep 29 16:18:45 raspberrypi charon: 13[CFG] candidate "IKEv2", match: 20/1/28 (me/other/ike) Sep 29 16:18:45 raspberrypi charon: 13[CFG] selected peer config 'IKEv2' Sep 29 16:18:45 raspberrypi charon: 13[IKE] no trusted RSA public key found for '10.218.49.167' Sep 29 16:18:45 raspberrypi charon: 13[IKE] processing INTERNAL_IP4_ADDRESS attribute Sep 29 16:18:45 raspberrypi charon: 13[IKE] processing INTERNAL_IP4_NETMASK attribute Sep 29 16:18:45 raspberrypi charon: 13[IKE] processing INTERNAL_IP4_DHCP attribute Sep 29 16:18:45 raspberrypi charon: 13[IKE] processing INTERNAL_IP4_DNS attribute Sep 29 16:18:45 raspberrypi charon: 13[IKE] processing INTERNAL_IP6_ADDRESS attribute Sep 29 16:18:45 raspberrypi charon: 13[IKE] processing INTERNAL_IP6_DHCP attribute Sep 29 16:18:45 raspberrypi charon: 13[IKE] processing INTERNAL_IP6_DNS attribute Sep 29 16:18:45 raspberrypi charon: 13[IKE] processing (25) attribute Sep 29 16:18:45 raspberrypi charon: 13[IKE] received ESP_TFC_PADDING_NOT_SUPPORTED, not using ESPv3 TFC padding Sep 29 16:18:45 raspberrypi charon: 13[IKE] peer supports MOBIKE Sep 29 16:18:45 raspberrypi charon: 13[ENC] generating IKE_AUTH response 1 [ N(AUTH_FAILED) ] Sep 29 16:18:45 raspberrypi charon: 13[NET] sending packet: from 192.168.123.101 to 94.109.49.167 (80 bytes) Sep 29 16:18:45 raspberrypi charon: 04[NET] sending packet: from 192.168.123.101 to 94.109.49.167 Sep 29 16:18:45 raspberrypi charon: 13[IKE] IKE_SA IKEv2 state change: CONNECTING => DESTROYING
