I have a problem with the built-in mic after an update. It worked normally before. I don't see it in the audio settings, and it is unplugged into the pavucontrol. Do someone have any advice?
OS: Pop!_OS 22.04 LTS
Kernel: 6.8.0-76060800daily20240311-generic
Notebook: https://psref.lenovo.com/Detail/ThinkPad/ThinkPad_T14_Gen_4_AMD?M=21K3003RCK
I tried the steps from https://support.system76.com/articles/audio/ : restart/reinstall pipwire, remove the configuration,...
systemctl --user status pipewire
● pipewire.service - PipeWire Multimedia Service
Loaded: loaded (/usr/lib/systemd/user/pipewire.service; enabled; vendor preset: enabled)
Active: active (running) since Fri 2024-06-07 14:05:14 CEST; 1h 9min ago
TriggeredBy: ● pipewire.socket
Main PID: 15298 (pipewire)
Tasks: 4 (limit: 36835)
Memory: 10.4M
CPU: 4.160s
CGroup: /user.slice/user-1000.slice/user@1000.service/session.slice/pipewire.service
└─15298 /usr/bin/pipewire
Jun 07 14:05:14 tp-lukas systemd: Started PipeWire Multimedia Service.
Jun 07 14:05:14 tp-lukas pipewire: mod.jackdbus-detect: Failed to receive jackdbus reply: org.freedesktop.DBus.Error.ServiceUnknown: The name is not activatable
systemctl --user status pipewire-pulse
● pipewire-pulse.service - PipeWire PulseAudio
Loaded: loaded (/usr/lib/systemd/user/pipewire-pulse.service; enabled; vendor preset: enabled)
Active: active (running) since Fri 2024-06-07 14:05:14 CEST; 1h 11min ago
TriggeredBy: ● pipewire-pulse.socket
Main PID: 15301 (pipewire-pulse)
Tasks: 3 (limit: 36835)
Memory: 27.8M
CPU: 3.829s
CGroup: /user.slice/user-1000.slice/user@1000.service/session.slice/pipewire-pulse.service
└─15301 /usr/bin/pipewire-pulse
Jun 07 14:05:14 tp-lukas systemd: Started PipeWire PulseAudio.
systemctl --user status wireplumber
● wireplumber.service - Multimedia Service Session Manager
Loaded: loaded (/usr/lib/systemd/user/wireplumber.service; enabled; vendor preset: enabled)
Active: active (running) since Fri 2024-06-07 14:05:14 CEST; 1h 12min ago
Main PID: 15300 (wireplumber)
Tasks: 5 (limit: 36835)
Memory: 6.0M
CPU: 395ms
CGroup: /user.slice/user-1000.slice/user@1000.service/session.slice/wireplumber.service
└─15300 /usr/bin/wireplumber
Jun 07 14:05:14 tp-lukas systemd: Started Multimedia Service Session Manager.
Jun 07 14:05:14 tp-lukas wireplumber: SPA handle 'api.libcamera.enum.manager' could not be loaded; is it installed?
Jun 07 14:05:14 tp-lukas wireplumber: PipeWire's libcamera SPA missing or broken. libcamera not supported.
Jun 07 14:05:15 tp-lukas wireplumber: Failed to call Lookup: GDBus.Error:org.freedesktop.portal.Error.NotFound: No entry for camera
Jun 07 14:05:15 tp-lukas wireplumber: Failed to call Lookup: GDBus.Error:org.freedesktop.portal.Error.NotFound: No entry for camera
Jun 07 14:05:15 tp-lukas wireplumber: Failed to call Lookup: GDBus.Error:org.freedesktop.portal.Error.NotFound: No entry for camera
lspci -v | grep -A6 Audio
pcilib: Error reading /sys/bus/pci/devices/0000:00:08.3/label: Operation not permitted
64:00.1 Audio device: Advanced Micro Devices, Inc. [AMD/ATI] Device 1640
Subsystem: Lenovo Device 50d9
Flags: bus master, fast devsel, latency 0, IRQ 92, IOMMU group 17
Memory at 785c8000 (32-bit, non-prefetchable) [size=16K]
Capabilities: Vendor Specific Information: Len=08
Capabilities: Power Management version 3
Capabilities: Express Legacy Endpoint, MSI 00
--
64:00.5 Multimedia controller: Advanced Micro Devices, Inc. [AMD] Raven/Raven2/FireFlight/Renoir Audio Processor (rev 63)
Subsystem: Lenovo Raven/Raven2/FireFlight/Renoir Audio Processor
Flags: bus master, fast devsel, latency 0, IRQ 91, IOMMU group 21
Memory at 78580000 (32-bit, non-prefetchable) [size=256K]
Memory at 1c10000000 (64-bit, prefetchable) [size=8M]
Capabilities: Vendor Specific Information: Len=08
Capabilities: Power Management version 3
Capabilities: Express Endpoint, MSI 00
--
64:00.6 Audio device: Advanced Micro Devices, Inc. [AMD] Family 17h (Models 10h-1fh) HD Audio Controller
Subsystem: Lenovo Family 17h (Models 10h-1fh) HD Audio Controller
Flags: bus master, fast devsel, latency 0, IRQ 93, IOMMU group 22
Memory at 785c0000 (32-bit, non-prefetchable) [size=32K]
Capabilities: Vendor Specific Information: Len=08
Capabilities: Power Management version 3
Capabilities: Express Endpoint, MSI 00
Capabilities: [a0] MSI: Enable+ Count=1/1 Maskable- 64bit+
arecord -l
**** List of CAPTURE Hardware Devices ****
card 1: Generic_1 [HD-Audio Generic], device 0: ALC257 Analog [ALC257 Analog]
Subdevices: 1/1
Subdevice #0: subdevice #0
pactl list cards
Card #49
Name: alsa_card.pci-0000_64_00.1
Driver: alsa
Owner Module: n/a
Properties:
api.acp.auto-port = "false"
api.acp.auto-profile = "false"
api.alsa.card = "0"
api.alsa.card.longname = "HD-Audio Generic at 0x785c8000 irq 92"
api.alsa.card.name = "HD-Audio Generic"
api.alsa.path = "hw:0"
api.alsa.use-acp = "true"
api.dbus.ReserveDevice1 = "Audio0"
device.api = "alsa"
device.bus = "pci"
device.bus_path = "pci-0000:64:00.1"
device.description = "HD-Audio Generic"
device.enum.api = "udev"
device.icon_name = "audio-card-analog-pci"
device.name = "alsa_card.pci-0000_64_00.1"
device.nick = "HD-Audio Generic"
device.plugged.usec = "80933960"
device.product.id = "0x1640"
device.subsystem = "sound"
sysfs.path = "/devices/pci0000:00/0000:00:08.1/0000:64:00.1/sound/card0"
device.vendor.id = "0x1002"
device.vendor.name = "Advanced Micro Devices, Inc. [AMD/ATI]"
media.class = "Audio/Device"
factory.id = "14"
client.id = "38"
object.id = "49"
object.serial = "49"
object.path = "alsa:pcm:0"
alsa.card = "0"
alsa.card_name = "HD-Audio Generic"
alsa.long_card_name = "HD-Audio Generic at 0x785c8000 irq 92"
alsa.driver_name = "snd_hda_intel"
device.string = "0"
Profiles:
off: Off (sinks: 0, sources: 0, priority: 0, available: yes)
output:hdmi-stereo: Digital Stereo (HDMI) Output (sinks: 1, sources: 0, priority: 5900, available: no)
output:hdmi-stereo-extra1: Digital Stereo (HDMI 2) Output (sinks: 1, sources: 0, priority: 5700, available: no)
output:hdmi-stereo-extra2: Digital Stereo (HDMI 3) Output (sinks: 1, sources: 0, priority: 5700, available: no)
output:hdmi-surround: Digital Surround 5.1 (HDMI) Output (sinks: 1, sources: 0, priority: 800, available: no)
output:hdmi-surround71: Digital Surround 7.1 (HDMI) Output (sinks: 1, sources: 0, priority: 800, available: no)
output:hdmi-surround-extra1: Digital Surround 5.1 (HDMI 2) Output (sinks: 1, sources: 0, priority: 600, available: no)
output:hdmi-surround71-extra1: Digital Surround 7.1 (HDMI 2) Output (sinks: 1, sources: 0, priority: 600, available: no)
output:hdmi-surround-extra2: Digital Surround 5.1 (HDMI 3) Output (sinks: 1, sources: 0, priority: 600, available: no)
output:hdmi-surround71-extra2: Digital Surround 7.1 (HDMI 3) Output (sinks: 1, sources: 0, priority: 600, available: no)
pro-audio: Pro Audio (sinks: 3, sources: 0, priority: 1, available: yes)
Active Profile: off
Ports:
hdmi-output-0: HDMI / DisplayPort (type: HDMI, priority: 5900, latency offset: 0 usec, availability group: Legacy 1, not available)
Properties:
port.type = "hdmi"
port.availability-group = "Legacy 1"
device.icon_name = "video-display"
card.profile.port = "0"
Part of profile(s): output:hdmi-stereo, output:hdmi-surround, output:hdmi-surround71
hdmi-output-1: HDMI / DisplayPort 2 (type: HDMI, priority: 5800, latency offset: 0 usec, availability group: Legacy 2, not available)
Properties:
port.type = "hdmi"
port.availability-group = "Legacy 2"
device.icon_name = "video-display"
card.profile.port = "1"
Part of profile(s): output:hdmi-stereo-extra1, output:hdmi-surround-extra1, output:hdmi-surround71-extra1
hdmi-output-2: HDMI / DisplayPort 3 (type: HDMI, priority: 5700, latency offset: 0 usec, availability group: Legacy 3, not available)
Properties:
port.type = "hdmi"
port.availability-group = "Legacy 3"
device.icon_name = "video-display"
card.profile.port = "2"
Part of profile(s): output:hdmi-stereo-extra2, output:hdmi-surround-extra2, output:hdmi-surround71-extra2
Card #50
Name: alsa_card.pci-0000_64_00.6
Driver: alsa
Owner Module: n/a
Properties:
api.acp.auto-port = "false"
api.acp.auto-profile = "false"
api.alsa.card = "1"
api.alsa.card.longname = "HD-Audio Generic at 0x785c0000 irq 93"
api.alsa.card.name = "HD-Audio Generic"
api.alsa.path = "hw:1"
api.alsa.use-acp = "true"
api.dbus.ReserveDevice1 = "Audio1"
device.api = "alsa"
device.bus = "pci"
device.bus_path = "pci-0000:64:00.6"
device.description = "Family 17h (Models 10h-1fh) HD Audio Controller"
device.enum.api = "udev"
device.icon_name = "audio-card-analog-pci"
device.name = "alsa_card.pci-0000_64_00.6"
device.nick = "HD-Audio Generic"
device.plugged.usec = "81012987"
device.product.id = "0x15e3"
device.product.name = "Family 17h (Models 10h-1fh) HD Audio Controller"
device.subsystem = "sound"
sysfs.path = "/devices/pci0000:00/0000:00:08.1/0000:64:00.6/sound/card1"
device.vendor.id = "0x1022"
device.vendor.name = "Advanced Micro Devices, Inc. [AMD]"
media.class = "Audio/Device"
factory.id = "14"
client.id = "38"
object.id = "50"
object.serial = "50"
object.path = "alsa:pcm:1"
alsa.card = "1"
alsa.card_name = "HD-Audio Generic"
alsa.long_card_name = "HD-Audio Generic at 0x785c0000 irq 93"
alsa.driver_name = "snd_hda_intel"
device.string = "1"
Profiles:
off: Off (sinks: 0, sources: 0, priority: 0, available: yes)
output:analog-stereo+input:analog-stereo: Analog Stereo Duplex (sinks: 1, sources: 1, priority: 6565, available: yes)
output:analog-stereo: Analog Stereo Output (sinks: 1, sources: 0, priority: 6500, available: yes)
input:analog-stereo: Analog Stereo Input (sinks: 0, sources: 1, priority: 65, available: no)
pro-audio: Pro Audio (sinks: 1, sources: 1, priority: 1, available: yes)
Active Profile: output:analog-stereo+input:analog-stereo
Ports:
analog-input-mic: Microphone (type: Mic, priority: 8700, latency offset: 0 usec, availability group: Legacy 1, not available)
Properties:
port.type = "mic"
port.availability-group = "Legacy 1"
device.icon_name = "audio-input-microphone"
card.profile.port = "0"
Part of profile(s): input:analog-stereo, output:analog-stereo+input:analog-stereo
analog-output-speaker: Speakers (type: Speaker, priority: 10000, latency offset: 0 usec, availability group: Legacy 2, availability unknown)
Properties:
port.type = "speaker"
port.availability-group = "Legacy 2"
device.icon_name = "audio-speakers"
card.profile.port = "1"
Part of profile(s): output:analog-stereo, output:analog-stereo+input:analog-stereo
analog-output-headphones: Headphones (type: Headphones, priority: 9900, latency offset: 0 usec, availability group: Legacy 3, not available)
Properties:
port.type = "headphones"
port.availability-group = "Legacy 3"
device.icon_name = "audio-headphones"
card.profile.port = "2"
Part of profile(s): output:analog-stereo, output:analog-stereo+input:analog-stereo
pactl list sources
Source #59
State: RUNNING
Name: alsa_output.pci-0000_64_00.6.analog-stereo.monitor
Description: Monitor of Family 17h (Models 10h-1fh) HD Audio Controller Analog Stereo
Driver: PipeWire
Sample Specification: s32le 2ch 44100Hz
Channel Map: front-left,front-right
Owner Module: 4294967295
Mute: no
Volume: front-left: 65536 / 100% / 0.00 dB, front-right: 65536 / 100% / 0.00 dB
balance 0.00
Base Volume: 65536 / 100% / 0.00 dB
Monitor of Sink: alsa_output.pci-0000_64_00.6.analog-stereo
Latency: 0 usec, configured 0 usec
Flags: HARDWARE DECIBEL_VOLUME LATENCY
Properties:
alsa.card = "1"
alsa.card_name = "HD-Audio Generic"
alsa.class = "generic"
alsa.device = "0"
alsa.driver_name = "snd_hda_intel"
alsa.id = "ALC257 Analog"
alsa.long_card_name = "HD-Audio Generic at 0x785c0000 irq 93"
alsa.name = "ALC257 Analog"
alsa.resolution_bits = "16"
alsa.subclass = "generic-mix"
alsa.subdevice = "0"
alsa.subdevice_name = "subdevice #0"
api.alsa.card.longname = "HD-Audio Generic at 0x785c0000 irq 93"
api.alsa.card.name = "HD-Audio Generic"
api.alsa.path = "front:1"
api.alsa.pcm.card = "1"
api.alsa.pcm.stream = "playback"
audio.channels = "2"
audio.position = "FL,FR"
card.profile.device = "3"
device.api = "alsa"
device.class = "monitor"
device.id = "50"
device.profile.description = "Analog Stereo"
device.profile.name = "analog-stereo"
device.routes = "2"
factory.name = "api.alsa.pcm.sink"
media.class = "Audio/Sink"
device.description = "Family 17h (Models 10h-1fh) HD Audio Controller"
node.name = "alsa_output.pci-0000_64_00.6.analog-stereo"
node.nick = "ALC257 Analog"
node.pause-on-idle = "false"
object.path = "alsa:pcm:1:front:1:playback"
priority.driver = "1009"
priority.session = "1009"
factory.id = "18"
clock.quantum-limit = "8192"
client.id = "38"
node.driver = "true"
factory.mode = "merge"
audio.adapt.follower = ""
library.name = "audioconvert/libspa-audioconvert"
object.id = "59"
object.serial = "59"
node.max-latency = "16384/44100"
api.alsa.period-size = "1024"
api.alsa.period-num = "32"
api.alsa.headroom = "0"
api.acp.auto-port = "false"
api.acp.auto-profile = "false"
api.alsa.card = "1"
api.alsa.use-acp = "true"
api.dbus.ReserveDevice1 = "Audio1"
device.bus = "pci"
device.bus_path = "pci-0000:64:00.6"
device.enum.api = "udev"
device.icon_name = "audio-card-analog-pci"
device.name = "alsa_card.pci-0000_64_00.6"
device.nick = "HD-Audio Generic"
device.plugged.usec = "81012987"
device.product.id = "0x15e3"
device.product.name = "Family 17h (Models 10h-1fh) HD Audio Controller"
device.subsystem = "sound"
sysfs.path = "/devices/pci0000:00/0000:00:08.1/0000:64:00.6/sound/card1"
device.vendor.id = "0x1022"
device.vendor.name = "Advanced Micro Devices, Inc. [AMD]"
device.string = "1"
Ports:
analog-output-speaker: Speakers (type: Speaker, priority: 10000, availability group: Legacy 2, availability unknown)
analog-output-headphones: Headphones (type: Headphones, priority: 9900, availability group: Legacy 3, not available)
Active Port: analog-output-speaker
Formats:
pcm
Source #60
State: SUSPENDED
Name: alsa_input.pci-0000_64_00.6.analog-stereo
Description: Family 17h (Models 10h-1fh) HD Audio Controller Analog Stereo
Driver: PipeWire
Sample Specification: s32le 2ch 48000Hz
Channel Map: front-left,front-right
Owner Module: 4294967295
Mute: no
Volume: front-left: 65536 / 100% / 0.00 dB, front-right: 65536 / 100% / 0.00 dB
balance 0.00
Base Volume: 65536 / 100% / 0.00 dB
Monitor of Sink: n/a
Latency: 0 usec, configured 0 usec
Flags: HARDWARE DECIBEL_VOLUME LATENCY
Properties:
alsa.card = "1"
alsa.card_name = "HD-Audio Generic"
alsa.class = "generic"
alsa.device = "0"
alsa.driver_name = "snd_hda_intel"
alsa.id = "ALC257 Analog"
alsa.long_card_name = "HD-Audio Generic at 0x785c0000 irq 93"
alsa.name = "ALC257 Analog"
alsa.resolution_bits = "16"
alsa.subclass = "generic-mix"
alsa.subdevice = "0"
alsa.subdevice_name = "subdevice #0"
api.alsa.card.longname = "HD-Audio Generic at 0x785c0000 irq 93"
api.alsa.card.name = "HD-Audio Generic"
api.alsa.path = "front:1"
api.alsa.pcm.card = "1"
api.alsa.pcm.stream = "capture"
audio.channels = "2"
audio.position = "FL,FR"
card.profile.device = "0"
device.api = "alsa"
device.class = "sound"
device.id = "50"
device.profile.description = "Analog Stereo"
device.profile.name = "analog-stereo"
device.routes = "1"
factory.name = "api.alsa.pcm.source"
media.class = "Audio/Source"
device.description = "Family 17h (Models 10h-1fh) HD Audio Controller"
node.name = "alsa_input.pci-0000_64_00.6.analog-stereo"
node.nick = "ALC257 Analog"
node.pause-on-idle = "false"
object.path = "alsa:pcm:1:front:1:capture"
priority.driver = "2009"
priority.session = "2009"
factory.id = "18"
clock.quantum-limit = "8192"
client.id = "38"
node.driver = "true"
factory.mode = "split"
audio.adapt.follower = ""
library.name = "audioconvert/libspa-audioconvert"
object.id = "60"
object.serial = "60"
api.acp.auto-port = "false"
api.acp.auto-profile = "false"
api.alsa.card = "1"
api.alsa.use-acp = "true"
api.dbus.ReserveDevice1 = "Audio1"
device.bus = "pci"
device.bus_path = "pci-0000:64:00.6"
device.enum.api = "udev"
device.icon_name = "audio-card-analog-pci"
device.name = "alsa_card.pci-0000_64_00.6"
device.nick = "HD-Audio Generic"
device.plugged.usec = "81012987"
device.product.id = "0x15e3"
device.product.name = "Family 17h (Models 10h-1fh) HD Audio Controller"
device.subsystem = "sound"
sysfs.path = "/devices/pci0000:00/0000:00:08.1/0000:64:00.6/sound/card1"
device.vendor.id = "0x1022"
device.vendor.name = "Advanced Micro Devices, Inc. [AMD]"
device.string = "1"
Ports:
analog-input-mic: Microphone (type: Mic, priority: 8700, availability group: Legacy 1, not available)
Active Port: analog-input-mic
Formats:
pcm
systemctl --user status pipewire
● pipewire.service - PipeWire Multimedia Service
Loaded: loaded (/usr/lib/systemd/user/pipewire.service; enabled; vendor preset: enabled)
Active: active (running) since Fri 2024-06-07 14:05:14 CEST; 1h 9min ago
TriggeredBy: ● pipewire.socket
Main PID: 15298 (pipewire)
Tasks: 4 (limit: 36835)
Memory: 10.4M
CPU: 4.160s
CGroup: /user.slice/user-1000.slice/user@1000.service/session.slice/pipewire.service
└─15298 /usr/bin/pipewire
Jun 07 14:05:14 tp-lukas systemd: Started PipeWire Multimedia Service.
Jun 07 14:05:14 tp-lukas pipewire: mod.jackdbus-detect: Failed to receive jackdbus reply: org.freedesktop.DBus.Error.ServiceUnknown: The name is not activatable
systemctl --user status pipewire-pulse
● pipewire-pulse.service - PipeWire PulseAudio
Loaded: loaded (/usr/lib/systemd/user/pipewire-pulse.service; enabled; vendor preset: enabled)
Active: active (running) since Fri 2024-06-07 14:05:14 CEST; 1h 11min ago
TriggeredBy: ● pipewire-pulse.socket
Main PID: 15301 (pipewire-pulse)
Tasks: 3 (limit: 36835)
Memory: 27.8M
CPU: 3.829s
CGroup: /user.slice/user-1000.slice/user@1000.service/session.slice/pipewire-pulse.service
└─15301 /usr/bin/pipewire-pulse
Jun 07 14:05:14 tp-lukas systemd: Started PipeWire PulseAudio.
systemctl --user status wireplumber
● wireplumber.service - Multimedia Service Session Manager
Loaded: loaded (/usr/lib/systemd/user/wireplumber.service; enabled; vendor preset: enabled)
Active: active (running) since Fri 2024-06-07 14:05:14 CEST; 1h 12min ago
Main PID: 15300 (wireplumber)
Tasks: 5 (limit: 36835)
Memory: 6.0M
CPU: 395ms
CGroup: /user.slice/user-1000.slice/user@1000.service/session.slice/wireplumber.service
└─15300 /usr/bin/wireplumber
Jun 07 14:05:14 tp-lukas systemd: Started Multimedia Service Session Manager.
Jun 07 14:05:14 tp-lukas wireplumber: SPA handle 'api.libcamera.enum.manager' could not be loaded; is it installed?
Jun 07 14:05:14 tp-lukas wireplumber: PipeWire's libcamera SPA missing or broken. libcamera not supported.
Jun 07 14:05:15 tp-lukas wireplumber: Failed to call Lookup: GDBus.Error:org.freedesktop.portal.Error.NotFound: No entry for camera
Jun 07 14:05:15 tp-lukas wireplumber: Failed to call Lookup: GDBus.Error:org.freedesktop.portal.Error.NotFound: No entry for camera
Jun 07 14:05:15 tp-lukas wireplumber: Failed to call Lookup: GDBus.Error:org.freedesktop.portal.Error.NotFound: No entry for camera
lspci -v | grep -A6 Audio
pcilib: Error reading /sys/bus/pci/devices/0000:00:08.3/label: Operation not permitted
64:00.1 Audio device: Advanced Micro Devices, Inc. [AMD/ATI] Device 1640
Subsystem: Lenovo Device 50d9
Flags: bus master, fast devsel, latency 0, IRQ 92, IOMMU group 17
Memory at 785c8000 (32-bit, non-prefetchable) [size=16K]
Capabilities: Vendor Specific Information: Len=08
Capabilities: Power Management version 3
Capabilities: Express Legacy Endpoint, MSI 00
--
64:00.5 Multimedia controller: Advanced Micro Devices, Inc. [AMD] Raven/Raven2/FireFlight/Renoir Audio Processor (rev 63)
Subsystem: Lenovo Raven/Raven2/FireFlight/Renoir Audio Processor
Flags: bus master, fast devsel, latency 0, IRQ 91, IOMMU group 21
Memory at 78580000 (32-bit, non-prefetchable) [size=256K]
Memory at 1c10000000 (64-bit, prefetchable) [size=8M]
Capabilities: Vendor Specific Information: Len=08
Capabilities: Power Management version 3
Capabilities: Express Endpoint, MSI 00
--
64:00.6 Audio device: Advanced Micro Devices, Inc. [AMD] Family 17h (Models 10h-1fh) HD Audio Controller
Subsystem: Lenovo Family 17h (Models 10h-1fh) HD Audio Controller
Flags: bus master, fast devsel, latency 0, IRQ 93, IOMMU group 22
Memory at 785c0000 (32-bit, non-prefetchable) [size=32K]
Capabilities: Vendor Specific Information: Len=08
Capabilities: Power Management version 3
Capabilities: Express Endpoint, MSI 00
Capabilities: [a0] MSI: Enable+ Count=1/1 Maskable- 64bit+
arecord -l
**** List of CAPTURE Hardware Devices ****
card 1: Generic_1 [HD-Audio Generic], device 0: ALC257 Analog [ALC257 Analog]
Subdevices: 1/1
Subdevice #0: subdevice #0
pactl list cards
Card #49
Name: alsa_card.pci-0000_64_00.1
Driver: alsa
Owner Module: n/a
Properties:
api.acp.auto-port = "false"
api.acp.auto-profile = "false"
api.alsa.card = "0"
api.alsa.card.longname = "HD-Audio Generic at 0x785c8000 irq 92"
api.alsa.card.name = "HD-Audio Generic"
api.alsa.path = "hw:0"
api.alsa.use-acp = "true"
api.dbus.ReserveDevice1 = "Audio0"
device.api = "alsa"
device.bus = "pci"
device.bus_path = "pci-0000:64:00.1"
device.description = "HD-Audio Generic"
device.enum.api = "udev"
device.icon_name = "audio-card-analog-pci"
device.name = "alsa_card.pci-0000_64_00.1"
device.nick = "HD-Audio Generic"
device.plugged.usec = "80933960"
device.product.id = "0x1640"
device.subsystem = "sound"
sysfs.path = "/devices/pci0000:00/0000:00:08.1/0000:64:00.1/sound/card0"
device.vendor.id = "0x1002"
device.vendor.name = "Advanced Micro Devices, Inc. [AMD/ATI]"
media.class = "Audio/Device"
factory.id = "14"
client.id = "38"
object.id = "49"
object.serial = "49"
object.path = "alsa:pcm:0"
alsa.card = "0"
alsa.card_name = "HD-Audio Generic"
alsa.long_card_name = "HD-Audio Generic at 0x785c8000 irq 92"
alsa.driver_name = "snd_hda_intel"
device.string = "0"
Profiles:
off: Off (sinks: 0, sources: 0, priority: 0, available: yes)
output:hdmi-stereo: Digital Stereo (HDMI) Output (sinks: 1, sources: 0, priority: 5900, available: no)
output:hdmi-stereo-extra1: Digital Stereo (HDMI 2) Output (sinks: 1, sources: 0, priority: 5700, available: no)
output:hdmi-stereo-extra2: Digital Stereo (HDMI 3) Output (sinks: 1, sources: 0, priority: 5700, available: no)
output:hdmi-surround: Digital Surround 5.1 (HDMI) Output (sinks: 1, sources: 0, priority: 800, available: no)
output:hdmi-surround71: Digital Surround 7.1 (HDMI) Output (sinks: 1, sources: 0, priority: 800, available: no)
output:hdmi-surround-extra1: Digital Surround 5.1 (HDMI 2) Output (sinks: 1, sources: 0, priority: 600, available: no)
output:hdmi-surround71-extra1: Digital Surround 7.1 (HDMI 2) Output (sinks: 1, sources: 0, priority: 600, available: no)
output:hdmi-surround-extra2: Digital Surround 5.1 (HDMI 3) Output (sinks: 1, sources: 0, priority: 600, available: no)
output:hdmi-surround71-extra2: Digital Surround 7.1 (HDMI 3) Output (sinks: 1, sources: 0, priority: 600, available: no)
pro-audio: Pro Audio (sinks: 3, sources: 0, priority: 1, available: yes)
Active Profile: off
Ports:
hdmi-output-0: HDMI / DisplayPort (type: HDMI, priority: 5900, latency offset: 0 usec, availability group: Legacy 1, not available)
Properties:
port.type = "hdmi"
port.availability-group = "Legacy 1"
device.icon_name = "video-display"
card.profile.port = "0"
Part of profile(s): output:hdmi-stereo, output:hdmi-surround, output:hdmi-surround71
hdmi-output-1: HDMI / DisplayPort 2 (type: HDMI, priority: 5800, latency offset: 0 usec, availability group: Legacy 2, not available)
Properties:
port.type = "hdmi"
port.availability-group = "Legacy 2"
device.icon_name = "video-display"
card.profile.port = "1"
Part of profile(s): output:hdmi-stereo-extra1, output:hdmi-surround-extra1, output:hdmi-surround71-extra1
hdmi-output-2: HDMI / DisplayPort 3 (type: HDMI, priority: 5700, latency offset: 0 usec, availability group: Legacy 3, not available)
Properties:
port.type = "hdmi"
port.availability-group = "Legacy 3"
device.icon_name = "video-display"
card.profile.port = "2"
Part of profile(s): output:hdmi-stereo-extra2, output:hdmi-surround-extra2, output:hdmi-surround71-extra2
Card #50
Name: alsa_card.pci-0000_64_00.6
Driver: alsa
Owner Module: n/a
Properties:
api.acp.auto-port = "false"
api.acp.auto-profile = "false"
api.alsa.card = "1"
api.alsa.card.longname = "HD-Audio Generic at 0x785c0000 irq 93"
api.alsa.card.name = "HD-Audio Generic"
api.alsa.path = "hw:1"
api.alsa.use-acp = "true"
api.dbus.ReserveDevice1 = "Audio1"
device.api = "alsa"
device.bus = "pci"
device.bus_path = "pci-0000:64:00.6"
device.description = "Family 17h (Models 10h-1fh) HD Audio Controller"
device.enum.api = "udev"
device.icon_name = "audio-card-analog-pci"
device.name = "alsa_card.pci-0000_64_00.6"
device.nick = "HD-Audio Generic"
device.plugged.usec = "81012987"
device.product.id = "0x15e3"
device.product.name = "Family 17h (Models 10h-1fh) HD Audio Controller"
device.subsystem = "sound"
sysfs.path = "/devices/pci0000:00/0000:00:08.1/0000:64:00.6/sound/card1"
device.vendor.id = "0x1022"
device.vendor.name = "Advanced Micro Devices, Inc. [AMD]"
media.class = "Audio/Device"
factory.id = "14"
client.id = "38"
object.id = "50"
object.serial = "50"
object.path = "alsa:pcm:1"
alsa.card = "1"
alsa.card_name = "HD-Audio Generic"
alsa.long_card_name = "HD-Audio Generic at 0x785c0000 irq 93"
alsa.driver_name = "snd_hda_intel"
device.string = "1"
Profiles:
off: Off (sinks: 0, sources: 0, priority: 0, available: yes)
output:analog-stereo+input:analog-stereo: Analog Stereo Duplex (sinks: 1, sources: 1, priority: 6565, available: yes)
output:analog-stereo: Analog Stereo Output (sinks: 1, sources: 0, priority: 6500, available: yes)
input:analog-stereo: Analog Stereo Input (sinks: 0, sources: 1, priority: 65, available: no)
pro-audio: Pro Audio (sinks: 1, sources: 1, priority: 1, available: yes)
Active Profile: output:analog-stereo+input:analog-stereo
Ports:
analog-input-mic: Microphone (type: Mic, priority: 8700, latency offset: 0 usec, availability group: Legacy 1, not available)
Properties:
port.type = "mic"
port.availability-group = "Legacy 1"
device.icon_name = "audio-input-microphone"
card.profile.port = "0"
Part of profile(s): input:analog-stereo, output:analog-stereo+input:analog-stereo
analog-output-speaker: Speakers (type: Speaker, priority: 10000, latency offset: 0 usec, availability group: Legacy 2, availability unknown)
Properties:
port.type = "speaker"
port.availability-group = "Legacy 2"
device.icon_name = "audio-speakers"
card.profile.port = "1"
Part of profile(s): output:analog-stereo, output:analog-stereo+input:analog-stereo
analog-output-headphones: Headphones (type: Headphones, priority: 9900, latency offset: 0 usec, availability group: Legacy 3, not available)
Properties:
port.type = "headphones"
port.availability-group = "Legacy 3"
device.icon_name = "audio-headphones"
card.profile.port = "2"
Part of profile(s): output:analog-stereo, output:analog-stereo+input:analog-stereo
pactl list sources
Source #59
State: RUNNING
Name: alsa_output.pci-0000_64_00.6.analog-stereo.monitor
Description: Monitor of Family 17h (Models 10h-1fh) HD Audio Controller Analog Stereo
Driver: PipeWire
Sample Specification: s32le 2ch 44100Hz
Channel Map: front-left,front-right
Owner Module: 4294967295
Mute: no
Volume: front-left: 65536 / 100% / 0.00 dB, front-right: 65536 / 100% / 0.00 dB
balance 0.00
Base Volume: 65536 / 100% / 0.00 dB
Monitor of Sink: alsa_output.pci-0000_64_00.6.analog-stereo
Latency: 0 usec, configured 0 usec
Flags: HARDWARE DECIBEL_VOLUME LATENCY
Properties:
alsa.card = "1"
alsa.card_name = "HD-Audio Generic"
alsa.class = "generic"
alsa.device = "0"
alsa.driver_name = "snd_hda_intel"
alsa.id = "ALC257 Analog"
alsa.long_card_name = "HD-Audio Generic at 0x785c0000 irq 93"
alsa.name = "ALC257 Analog"
alsa.resolution_bits = "16"
alsa.subclass = "generic-mix"
alsa.subdevice = "0"
alsa.subdevice_name = "subdevice #0"
api.alsa.card.longname = "HD-Audio Generic at 0x785c0000 irq 93"
api.alsa.card.name = "HD-Audio Generic"
api.alsa.path = "front:1"
api.alsa.pcm.card = "1"
api.alsa.pcm.stream = "playback"
audio.channels = "2"
audio.position = "FL,FR"
card.profile.device = "3"
device.api = "alsa"
device.class = "monitor"
device.id = "50"
device.profile.description = "Analog Stereo"
device.profile.name = "analog-stereo"
device.routes = "2"
factory.name = "api.alsa.pcm.sink"
media.class = "Audio/Sink"
device.description = "Family 17h (Models 10h-1fh) HD Audio Controller"
node.name = "alsa_output.pci-0000_64_00.6.analog-stereo"
node.nick = "ALC257 Analog"
node.pause-on-idle = "false"
object.path = "alsa:pcm:1:front:1:playback"
priority.driver = "1009"
priority.session = "1009"
factory.id = "18"
clock.quantum-limit = "8192"
client.id = "38"
node.driver = "true"
factory.mode = "merge"
audio.adapt.follower = ""
library.name = "audioconvert/libspa-audioconvert"
object.id = "59"
object.serial = "59"
node.max-latency = "16384/44100"
api.alsa.period-size = "1024"
api.alsa.period-num = "32"
api.alsa.headroom = "0"
api.acp.auto-port = "false"
api.acp.auto-profile = "false"
api.alsa.card = "1"
api.alsa.use-acp = "true"
api.dbus.ReserveDevice1 = "Audio1"
device.bus = "pci"
device.bus_path = "pci-0000:64:00.6"
device.enum.api = "udev"
device.icon_name = "audio-card-analog-pci"
device.name = "alsa_card.pci-0000_64_00.6"
device.nick = "HD-Audio Generic"
device.plugged.usec = "81012987"
device.product.id = "0x15e3"
device.product.name = "Family 17h (Models 10h-1fh) HD Audio Controller"
device.subsystem = "sound"
sysfs.path = "/devices/pci0000:00/0000:00:08.1/0000:64:00.6/sound/card1"
device.vendor.id = "0x1022"
device.vendor.name = "Advanced Micro Devices, Inc. [AMD]"
device.string = "1"
Ports:
analog-output-speaker: Speakers (type: Speaker, priority: 10000, availability group: Legacy 2, availability unknown)
analog-output-headphones: Headphones (type: Headphones, priority: 9900, availability group: Legacy 3, not available)
Active Port: analog-output-speaker
Formats:
pcm
Source #60
State: SUSPENDED
Name: alsa_input.pci-0000_64_00.6.analog-stereo
Description: Family 17h (Models 10h-1fh) HD Audio Controller Analog Stereo
Driver: PipeWire
Sample Specification: s32le 2ch 48000Hz
Channel Map: front-left,front-right
Owner Module: 4294967295
Mute: no
Volume: front-left: 65536 / 100% / 0.00 dB, front-right: 65536 / 100% / 0.00 dB
balance 0.00
Base Volume: 65536 / 100% / 0.00 dB
Monitor of Sink: n/a
Latency: 0 usec, configured 0 usec
Flags: HARDWARE DECIBEL_VOLUME LATENCY
Properties:
alsa.card = "1"
alsa.card_name = "HD-Audio Generic"
alsa.class = "generic"
alsa.device = "0"
alsa.driver_name = "snd_hda_intel"
alsa.id = "ALC257 Analog"
alsa.long_card_name = "HD-Audio Generic at 0x785c0000 irq 93"
alsa.name = "ALC257 Analog"
alsa.resolution_bits = "16"
alsa.subclass = "generic-mix"
alsa.subdevice = "0"
alsa.subdevice_name = "subdevice #0"
api.alsa.card.longname = "HD-Audio Generic at 0x785c0000 irq 93"
api.alsa.card.name = "HD-Audio Generic"
api.alsa.path = "front:1"
api.alsa.pcm.card = "1"
api.alsa.pcm.stream = "capture"
audio.channels = "2"
audio.position = "FL,FR"
card.profile.device = "0"
device.api = "alsa"
device.class = "sound"
device.id = "50"
device.profile.description = "Analog Stereo"
device.profile.name = "analog-stereo"
device.routes = "1"
factory.name = "api.alsa.pcm.source"
media.class = "Audio/Source"
device.description = "Family 17h (Models 10h-1fh) HD Audio Controller"
node.name = "alsa_input.pci-0000_64_00.6.analog-stereo"
node.nick = "ALC257 Analog"
node.pause-on-idle = "false"
object.path = "alsa:pcm:1:front:1:capture"
priority.driver = "2009"
priority.session = "2009"
factory.id = "18"
clock.quantum-limit = "8192"
client.id = "38"
node.driver = "true"
factory.mode = "split"
audio.adapt.follower = ""
library.name = "audioconvert/libspa-audioconvert"
object.id = "60"
object.serial = "60"
api.acp.auto-port = "false"
api.acp.auto-profile = "false"
api.alsa.card = "1"
api.alsa.use-acp = "true"
api.dbus.ReserveDevice1 = "Audio1"
device.bus = "pci"
device.bus_path = "pci-0000:64:00.6"
device.enum.api = "udev"
device.icon_name = "audio-card-analog-pci"
device.name = "alsa_card.pci-0000_64_00.6"
device.nick = "HD-Audio Generic"
device.plugged.usec = "81012987"
device.product.id = "0x15e3"
device.product.name = "Family 17h (Models 10h-1fh) HD Audio Controller"
device.subsystem = "sound"
sysfs.path = "/devices/pci0000:00/0000:00:08.1/0000:64:00.6/sound/card1"
device.vendor.id = "0x1022"
device.vendor.name = "Advanced Micro Devices, Inc. [AMD]"
device.string = "1"
Ports:
analog-input-mic: Microphone (type: Mic, priority: 8700, availability group: Legacy 1, not available)
Active Port: analog-input-mic
Formats:
pcm
Asked by Lukáš Križan
(11 rep)
Jun 7, 2024, 01:41 PM
